Pulse pressure variation and volume responsiveness during acutely increased pulmonary artery pressure: an experimental study
Critical Care volume 14, Article number: R122 (2010)
We found that pulse pressure variation (PPV) did not predict volume responsiveness in patients with increased pulmonary artery pressure. This study tests the hypothesis that PPV does not predict fluid responsiveness during an endotoxin-induced acute increase in pulmonary artery pressure and right ventricular loading.
Pigs were subjected to endotoxemia (0.4 μg/kg/hour lipopolysaccharide), followed by volume expansion, subsequent hemorrhage (20% of estimated blood volume), retransfusion, and additional stepwise volume loading until cardiac output did not increase further (n = 5). A separate control group (n = 7) was subjected to bleeding, retransfusion, and volume expansion without endotoxemia. Systemic hemodynamics were measured at baseline and after each intervention, and PPV was calculated offline. Prediction of fluid-challenge-induced stroke volume increase by PPV was analyzed using receiver operating characteristic (ROC) curves.
Sixty-eight volume challenges were performed in endotoxemic animals (22 before and 46 after hemorrhage), and 51 volume challenges in the controls. Endotoxin infusion resulted in an acute increase in pulmonary artery and central venous pressure and a decrease in stroke volume (all P < 0.05). In endotoxemia, 68% of volume challenges before hemorrhage increased the stroke volume by > 10%, but PPV did not predict fluid responsiveness (area under the ROC curve = 0.604, P = 0.461). After hemorrhage in endotoxemia, stroke volume increased in 48% and the predictive value of PPV improved (area under the ROC curve for PPV = 0.699, P = 0.021). In controls after hemorrhage, stroke volume increased in 67% of volume challenges and PPV was a predictor of fluid responsiveness (area under the ROC curve = 0.790, P = 0.001).
Fluid responsiveness cannot be predicted with PPV during acute pulmonary hypertension in porcine endotoxemia. Even following severe hemorrhage during endotoxemia, the predictive value of PPV is marginal.
Fluid challenges are frequently used to treat hemodynamically unstable patients, in order to enhance cardiac function by increasing preload. Once the flat part of the cardiac function curve has been reached, the patients are no longer volume responsive . In such cases, further fluid administration can be detrimental due to unnecessary loading of the heart, increased tissue edema, and consequent risk of impaired tissue perfusion.
Cyclic variations of intrathoracic pressure during mechanical ventilation induce acute alterations in cardiac preload and afterload, and are reflected in arterial pressure. Several studies have proposed that pulse pressure variation (PPV) can be used to predict volume responsiveness in mechanically ventilated patients [2–4]. In hypovolemia, the heart operates on the steep part of the cardiac function curve. Hence, the preload reduction induced by positive inspiratory pressure should enhance stroke volume variation and PPV. This hypothesis has been demonstrated in experimental studies  and in patients [2, 3, 6–8], and has been widely adopted in clinical practice to guide fluid therapy.
False-positive predictions of fluid responsiveness with PPV are not uncommon in clinical practice. Acute right ventricular dysfunction can also increase PPV if the increase in afterload due to positive intrathoracic pressure is more relevant than the concomitant reduction in venous return . A failing right ventricle may also impair left ventricular filling during inspiration. A clinically relevant number of false-positive PPVs have been reported recently in critically ill patients with right ventricular dysfunction .
Acute right ventricular failure is common in intensive care unit patients, and may occur in about one-third of patients with septic shock [11, 12]. In an accompanying paper, we have shown that PPV does not predict fluid responsiveness in critically ill patients with increased pulmonary arterial pressure . The aim of the present study was to validate these findings in pigs in which pulmonary artery pressure was acutely increased by endotoxin infusion.
Materials and methods
The study was performed in accordance with the National Institutes of Health guidelines for the care and use of experimental animals, and with the approval of the Animal Care Committee of the Canton of Bern, Switzerland.
Anesthesia and monitoring
Thirteen pigs (body weight 37 to 48 kg, five females) were deprived of food but not of water for 24 hours before the experiments. They were premedicated with atropine 0.05 mg/kg body weight and azaperon (Stresnil®; Janssen Pharmaceutica, Beerse, Belgium) 4 mg/kg intramuscularly, followed by cannulation of an ear vein and intravenous administration of 8 to 10 mg/kg pentobarbital (Vetanarchol®; Veterinaria AG, Zürich, Switzerland) for endotracheal intubation 5 minutes later. Anesthesia was maintained with pentobarbital 6 to 12 mg/kg/hour and fentanyl 30 μg/kg/hour until the end of the operation.
After the end of the preparation phase, fentanyl was reduced to 5 μg/kg/hour. Neuromuscular blockade was maintained by continuous infusion of pancuronium (Pavulon®; Organon, Pfäffikon, Switzerland) to suppress spontaneous breathing and to avoid shivering. The animals were ventilated with a volume-controlled ventilator (Servo 900C; Siemens, Erlangen, Germany) with 5 cmH2O positive end-expiratory pressure. FIO2 was adjusted to keep PaO2 levels between 100 mmHg (13.3 kPa) and 150 mmHg (20 kPa), and remained constant throughout the experiment. The tidal volume was kept at 10 ml/kg and the minute ventilation was adjusted to maintain PaCO2 levels between 34 and 41 mmHg (4.5 to 5.5 kPa); after initial adjustment of minute ventilation, the tidal volume was kept constant during the experiment. During animal preparation, 150 ml hydroxyethyl starch (Voluven 6%; Fresenius Kabi AG, Stans, Switzerland) was given in all pigs. Blood losses were substituted additionally with hydroxyethyl starch.
After induction of anesthesia, the carotid artery and femoral and jugular veins were exposed surgically. A pulmonary artery catheter (CO/SvO2 Catheter; Edwards Lifesciences, Irvine, CA, USA) was inserted via the jugular vein under pressure monitoring. A carotid artery catheter and a femoral venous large bore intravascular sheet for fluid removal and administration were inserted.
Hemodynamic monitoring and data recording
Intravascular pressures were recorded with quartz pressure transducers, displayed continuously on a multimodular monitor together with the airway pressure (S/5 Critical Care Monitor; Datex-Ohmeda, Helsinki, Finland), and recorded on a computer at a sampling rate of 300 Hz (S-Collect software; Datex-Ohmeda). All pressure transducers were calibrated simultaneously and were zeroed to the level of the heart. Cardiac output was measured using the thermodilution technique (mean value of three bolus measurements using cold saline boluses). The heart rate was measured from the continuously monitored electrocardiogram, and the stroke volume was calculated by dividing cardiac output by the heart rate. After each step of bleeding and each volume challenge, hemodynamic variables were recorded for data analysis.
After preparation and catheter insertion, 30 minutes were allowed for hemodynamic stabilization. An infusion of Ringer's lactate (Sintetica-Bioren SA, Couvet, Switzerland) was set at 2 ml/kg throughout the experiment. After baseline measurements, endotoxin (Escherichia coli lipopolysaccharide B0111:B4; Difco Laboratories, Detroit, MI, USA) was infused in the right atrium of five animals at an initial rate of 0.4 μg/kg/hour until the mean pulmonary artery pressure reached two-thirds of the mean systemic pressure. The infusion was then stopped and subsequently adjusted to maintain moderate pulmonary hypertension (mean pulmonary artery pressure, 30 to 35 mmHg). Hydroxyethyl starch (Voluven 6%; Fresenius Kabi AG) was rapidly injected using a 50 ml syringe in boluses of 10% of the estimated blood volume (75 ml/kg ) as long as the cardiac output increased > 10%. Volume loading was stopped when two consecutive volume challenges showed no increase in cardiac output > 10%.
Subsequently, the animals were bled by increments of 10% of their estimated blood volume up to a blood loss of 20%. Bleeding was aborted when the systolic blood pressure was below 45 mmHg or the cardiac output was below 1.5 l/minute. The shed blood was then retransfused and additional volume challenges were administered in the form of hydroxyethyl starch in portions of 10% of the estimated blood volume, until cardiac output did not increase further. At the end of the experiment, the animals were sacrificed with an injection of 20 mmol potassium chloride.
A protocol of bleeding up to a blood loss of 20%, retransfusion and further volume expansion was also performed in a separate control group of eight animals.
Analysis of arterial pressure waveforms
The pressures were analyzed offline. Systolic and diastolic arterial pressures were measured on a beat-to-beat basis, and the pulse pressure was calculated as the difference between systolic and diastolic pressures. Maximal and minimal systolic pressures (Ps max and Ps min) and pulse pressures (Pp max and Pp min) were determined over a single respiratory cycle. PPV was calculated as :
End-tidal carbon dioxide and airway pressure signals were used to define the respiratory cycle.
Evaluation of volume response
Changes in stroke volume were used to define response to volume challenge. An increase in stroke volume ≥10% following volume administration was considered a positive response. The volume challenge should increase the stroke volume as a result of acutely increased preload in a heart operating on the steep portion of the cardiac function curve. The results were therefore analyzed in two ways: including all volume challenges, and including only those resulting in an increase in central venous pressure (CVP) > 1 mmHg.
The SPSS for Windows 12.0.1 software package (SPSS Inc., Chicago, IL, USA) was used for statistical analysis. Distribution characteristics were assessed using the Kolmogorov-Smirnov test. Data are expressed as mean ± standard deviation if not stated otherwise. Comparison of several means was performed using repeated-measures analysis of variance and Scheffe's test for post hoc analysis. The effects of fluid administration on hemodynamic parameters were assessed using the paired t test or the Wilcoxon rank sum test. Proportions were compared using Fisher's exact test. Receiver operating characteristic (ROC) curves were constructed to evaluate the predictive value of PPV. The best predictive threshold was defined as the highest sum of sensitivity and specificity. In addition, the predictive value of a PPV threshold of 13% was also evaluated. Data are presented as percentages (proportional data) and as mean ± standard deviation (hemodynamic variables). P < 0.05 was considered statistically significant.
One animal from the group with bleeding and without endotoxemia died during the first step of bleeding due to ventricular fibrillation, and was therefore excluded. All pigs in the endotoxin group tolerated the lipopolysaccharide dose of 0.4 μg/kg/hour. Endotoxin infusion resulted in tachycardia, increased pulmonary artery and central venous pressures, and decreased stroke volume (all P < 0.05), but no change in PPV (Table 1). During the volume expansion a total of 1,250 ± 160 ml fluid was infused, followed by 1,540 ± 150 ml of bleeding. Subsequent retransfusion and further volume loading added up to 2,660 ± 560 ml. In the control group, a total of 600 ± 80 ml fluid was bled, followed by retransfusion and further volume loading for a total of 2,260 ± 280 ml. The hemodynamics are summarized in Table 1.
Sixty-eight fluid challenges were performed during endotoxemia (22 before bleeding and 46 during retransfusion and volume expansion; Table 2), and 37 of these (54%) increased stroke volume. If only fluid challenges that increased the CVP by > 1 mmHg are considered (n = 60), then 34 (57%) challenges increased the stroke volume.
Fifty-one fluid challenges were performed in controls (Table 2), and 34 of these (67%) increased the stroke volume. If only fluid challenges that increased the CVP by > 1 mmHg are considered (n = 39), then 28 (72%) challenges increased the stroke volume. Table 3 summarizes the hemodynamics before and after the fluid challenges in responders and nonresponders in both groups of animals. The cardiac function curves under different conditions are displayed in Figures 1, 2 and 3.
Pulse pressure variation and volume responsiveness
PPV was a poor predictor of an increase in stroke volume in endotoxemia, and did not predict volume responsiveness before bleeding. The area under the ROC curve (Figures 4, 5, 6 and 7) was 0.642 for all fluid challenges during endotoxemia (P = 0.045; Table 2), and this was related to the fluid challenges performed after bleeding (area under the ROC curve = 0.699, P = 0.021). In controls, PPV was a predictor of stroke volume increase (area under the ROC curve = 0.790, P = 0.001). Inclusion of only those fluid challenges with a CVP increase did not improve the prediction of increase in stroke volume.
The threshold values for best prediction (even if the area under the ROC curve was not significant) varied from 9 to 12% (Table 2). Using the cut-off value of 9% resulted in a sensitivity of 0.84 (95% confidence interval = 0.68 to 0.94) and a specificity of 0.39 (95% confidence interval = 0.22 to 0.58). The positive predictive value was 0.62 (95% confidence interval = 0.47 to 0.75) and the negative predictive value was 0.67 (95% confidence interval = 0.41 to 0.87).
Using a PPV threshold ≥13% resulted in a sensitivity of 0.46 (95% confidence interval = 0.30 to 0.63) and a specificity of 0.74 (95% confidence interval = 0.55 to 0.88). The positive predictive value was 0.68 (95% confidence interval = 0.46 to 0.85) and the negative predictive value was 0.53 (95% confidence interval = 0.38 to 0.69).
The main finding of the present study was that the predictive value of PPV for volume responsiveness is modified during an endotoxemia-induced acute increase in pulmonary artery pressure. In hemorrhage-induced hypovolemia, PPV could predict volume responsiveness, as expected. In contrast, during acutely increased pulmonary artery pressure in endotoxemia, the predictive value of PPV for volume responsiveness was lost. This is very similar to our finding of the poor predictive value of PPV for volume responsiveness in patients with elevated pulmonary artery pressure . While our present findings provide proof for the concept that PPV may not predict volume responsiveness in the presence of pulmonary artery hypertension, there are relevant differences between the two studies and limitations that need to be considered.
First, in this experimental study, pulmonary artery hypertension was induced very acutely in pigs with previously healthy hearts; whereas in the clinical study, pulmonary hypertension was either due to sepsis or to pre-existing cardiac disease with mild to moderately elevated pulmonary artery pressure. In patients with sepsis, global myocardial dysfunction is likely to be present , and patients after cardiac surgery are likely to have postoperative myocardial dysfunction ; in addition, there is an increased risk of right ventricular dysfunction in the early postoperative period [17, 18]. The consequences of acute changes in right ventricular loading were likely to represent those observed in patients, however, because pigs also demonstrated signs of acute heart dysfunction after endotoxemia.
Second, the magnitude of PPV between the studies was different: the mean PPV at baseline (13%) and before volume loading in the endotoxemic animals (10%) as well as in controls (11%) was comparable with values reported in healthy pigs [19, 20] and in healthy dogs . In the accompanying paper, the mean PPV in patients with septic shock (mean 27%) and in patients after cardiac surgery (mean 20%) was considerably higher, despite the use of a moderate tidal volume of 8 to 10 ml/kg . These differences may be explained at least in part by species-related differences in the mechanical properties of the cardiovascular system, as well as in the thorax and the abdomen. The PPV values we found in patients were higher than in most studies previously reported in the literature. In cardiac surgery patients, PPV ranging from 11 to 15% (15 to 20% in responders) has been reported [22–30]; and in septic patients, PPV from 9 to 19% (13 to 24% in responders) [3, 31–35]. As discussed in detail in the accompanying paper, the patients also had substantially higher pulmonary artery pressures than have been reported by others . In the present study, the pulmonary artery pressure was increased even further.
Third, the cardiovascular effects of endotoxin are not limited to increased pulmonary artery pressure and acute right ventricular loading [36–38]. Endotoxin may impair the systolic and diastolic functions of both ventricles to a variable extent, and the overall impact may therefore also vary. Perhaps the most important difference between our two studies was that, despite the loss of the predictive value of PPV in both studies, the pigs remained volume responsive whereas most of the patients were nonresponders. This strongly suggests that different mechanisms may have been present to explain the poor predictive value of PPV. The lack of volume responsiveness in the patients was frequently associated with decreased right ventricular ejection fraction, suggesting impaired systolic function. In contrast, in the present study the pigs had severely reduced stroke volume and increased filling pressures but mostly preserved volume responsiveness. This suggests a relevant impairment of diastolic function and increased elastance. It is conceivable that systolic and diastolic dysfunction coexist to a variable extent, and their relevance to fluid responsiveness may also be modified by fluid challenges (for example, due to an acute septal shift).
Since we did not perform echocardiography, no conclusions on the exact mechanisms can be made. It should be acknowledged, however, that the contribution of Δup to the PPV (decrease in afterload with inspiration and squeezing of blood out of the lungs) is affected by the volume of blood in the lungs (likely to be higher in septic animals) and by the function of the left heart (likely to be more afterload-responsive in endotoxic animals). The afterload-reducing effect is related to how much pleural pressure rises with breaths, which will be increased if the chest wall compliance is reduced by edema (as expected with volume loading). This effect could be operative at higher volumes.
Another variable is tidal volume, which was kept constant. With decreasing chest wall and lung compliance, however, a constant tidal volume will be associated with increased pleural pressure swings. Besides affecting left ventricular afterload, the pleural pressure inhibits venous return, which should increase PPV. A complicating factor, however, is that pleural pressure also may increase the creation of zone II areas in the lung, which increases the afterload on the right ventricle and reduces the right ventricular stroke volume. This decrease is not volume responsive when the heart is functioning on the plateau of its function curve. This seems to be a likely explanation for our findings.
A further complicating variable is the abdominal reservoir, which increases when the animals are volume loaded as in our experiments. The descent of the diaphragm can therefore result in transfer of abdominal volume to the chest, and thus in an increase of right ventricular filling during inspiration.
These pathophysiological considerations demonstrate the complexities of PPV, which should be addressed in further studies. Nevertheless, our two studies clearly demonstrate that the predictive value of PPV for fluid responsiveness is lost under various conditions with increased pulmonary artery pressure. Although acute severe hypovolemia induced by bleeding restored some of the predictive value of PPV in endotoxemia, this is a rare clinical scenario. The high false-positive rate of PPV in predicting fluid responsiveness was recently shown by Mahjoub and colleagues . Those authors considered it relevant enough to warrant echocardiography before fluid challenges are performed in patients with increased PPV.
Two limitations of the present paper, and a general limitation of the "PPV as a predictor of stroke volume response" approach, should briefly be addressed. First, the number of pigs in the present study is relatively small. In terms of fluid challenges, however, this study is certainly one of the largest. Second, PPV has been analyzed over only one respirator cycle in our study. Nevertheless, we did not find different values when analyzing PPV over five consecutive respiratory cycles at various time points in the experimental protocol.
The percentage of stroke volume increase has generally been used along with PPV as a criterion of volume response. With large variations of stroke volume, however, the requested percentage for a significant increase of stroke volume (usually 10%) may represent absolute changes that range from clinically highly significant to negligible.
Finally, we would like to acknowledge that the model we used for fluid administration was designed to test the ability of PPV to predict fluid responsiveness. In a clinical situation, double-checking the lack of response to a fluid challenge does not make sense.
Our two studies suggest that both false-positive and false-negative values are common for PPV when the pulmonary artery pressure is increased. Increased pulmonary artery pressure is common in intensive care patients, especially in sepsis and after cardiac surgery, but may be overlooked unless echocardiography or the pulmonary artery catheter is used. We therefore strongly suggest caution in using PPV to predict volume responsiveness.
PPV does not predict fluid responsiveness during endotoxin-induced pulmonary artery hypertension.
During severe hemorrhage in endotoxemia, the predictive value of PPV is low.
Volume challenges triggered by high PPV may lead to fluid accumulation in these situations.
The authors would like to express gratitude to Olgica Beslac, Dr Daniel Mettler, and Daniel Zalokar for their skillful assistance during the experiments, and to Jeannie Wurz for editing the manuscript.
central venous pressure
pulse pressure variation
receiver operating characteristic.
Michard F, Teboul JL: Using heart-lung interactions to assess fluid responsiveness during mechanical ventilation. Crit Care 2000, 4: 282-289. 10.1186/cc710
Coyle JP, Teplick RS, Long MC: Respiratory variations in systemic arterial pressure as an indicator of volume status. Anesthesiology 1983, 59: A53.
Michard F, Boussat S, Chemla D, Anguel N, Mercat A, Lecarpentier Y, Richard C, Pinsky MR, Teboul JL: Relation between respiratory changes in arterial pulse pressure and fluid responsiveness in septic patients with acute circulatory failure. Am J Respir Crit Care Med 2000, 162: 134-138.
Reuter DA, Felbinger TW, Schmidt C, Kilger E, Goedje O, Lamm P, Goetz AE: Stroke volume variations for assessment of cardiac responsiveness to volume loading in mechanically ventilated patients after cardiac surgery. Intensive Care Med 2002, 28: 392-398. 10.1007/s00134-002-1211-z
Perel A, Pizov R, Cotev S: Systolic blood pressure variation is a sensitive indicator of hypovolemia in ventilated dogs subjected to graded hemorrhage. Anesthesiology 1987, 67: 498-502. 10.1097/00000542-198710000-00009
Coriat P, Vrillon M, Perel A, Baron JF, Le Bret F, Saada M, Viars P: A comparison of systolic blood pressure variations and echocardiographic estimates of end-diastolic left ventricular size in patients after aortic surgery. Anesth Analg 1994, 78: 46-53. 10.1213/00000539-199401000-00009
Rooke GA, Schwid HA, Shapira Y: The effect of graded hemorrhage and intravascular volume replacement on systolic pressure variation in humans during mechanical and spontaneous ventilation. Anesth Analg 1995, 80: 925-932. 10.1097/00000539-199505000-00012
Michard F, Chemla D, Richard C, Wysocki M, Pinsky MR, Lecarpentier Y, Teboul JL: Clinical use of respiratory changes in arterial pulse pressure to monitor the hemodynamic effects of PEEP. Am J Respir Crit Care Med 1999, 159: 935-939.
Jardin F: Cyclic changes in arterial pressure during mechanical ventilation. Intensive Care Med 2004, 30: 1047-1050. 10.1007/s00134-004-2254-0
Mahjoub Y, Pila C, Friggeri A, Zogheib E, Lobjoie E, Tinturier F, Galy C, Slama M, Dupont H: Assessing fluid responsiveness in critically ill patients: false-positive pulse pressure variation is detected by Doppler echocardiographic evaluation of the right ventricle. Crit Care Med 2009, 37: 2570-2575. 10.1097/CCM.0b013e3181a380a3
Jardin F, Brun-Ney D, Auvert B, Beauchet A, Bourdarias JP: Sepsis-related cardiogenic shock. Crit Care Med 1990, 18: 1055-1060. 10.1097/00003246-199010000-00001
Vieillard Baron A, Schmitt JM, Beauchet A, Augarde R, Prin S, Page B, Jardin F: Early preload adaptation in septic shock? A transesophageal echocardiographic study. Anesthesiology 2001, 94: 400-406. 10.1097/00000542-200103000-00007
Wyler von Ballmoos M, Takala J, Roeck M, Porta F, Tueller D, Ganter CC, Schroeder R, Bracht H, Baenziger B, Jakob SM: Pulse pressure variation and hemodynamic response in patients with elevated pulmonary artery pressure. Crit Care 2010, 14: R111. 10.1186/cc9060
Preisman S, DiSegni E, Vered Z, Perel A: Left ventricular preload and function during graded haemorrhage and retranfusion in pigs: analysis of arterial pressure waveform and correlation with echocardiography. Br J Anaesth 2002, 88: 716-718. 10.1093/bja/88.5.716
Poelaert J, Declerck C, Vogelaers D, Colardyn F, Visser CA: Left ventricular systolic and diastolic function in septic shock. Intensive Care Med 1997, 23: 553-560. 10.1007/s001340050372
Gerber BL, Ordoubadi FF, Wijns W, Vanoverschelde JL, Knuuti MJ, Janier M, Melon P, Blanksma PK, Bol A, Bax JJ, Melin JA, Camici PG: Positron emission tomography using 18F-fluoro-deoxyglucose and euglycaemic hyperinsulinaemic glucose clamp: optimal criteria for the prediction of recovery of post-ischaemic left ventricular dysfunction. Results from the European Community Concerted Action Multicenter study on use of 18F-fluoro-deoxyglucose positron emission tomography for the detection of myocardial viability. Eur Heart J 2001, 22: 1691-1701. 10.1053/euhj.2000.2585
Viitanen A, Salmenpera M, Heinonen J: Right ventricular response to hypercarbia after cardiac surgery. Anesthesiology 1990, 73: 393-400. 10.1097/00000542-199009000-00005
Robitaille A, Denault AY, Couture P, Belisle S, Fortier A, Guertin MC, Carrier M, Martineau R: Importance of relative pulmonary hypertension in cardiac surgery: the mean systemic-to-pulmonary artery pressure ratio. J Cardiothorac Vasc Anesth 2006, 20: 331-339. 10.1053/j.jvca.2005.11.018
Renner J, Gruenewald M, Quaden R, Hanss R, Meybohm P, Steinfath M, Scholz J, Bein B: Influence of increased intra-abdominal pressure on fluid responsiveness predicted by pulse pressure variation and stroke volume variation in a porcine model. Crit Care Med 2009, 37: 650-658. 10.1097/CCM.0b013e3181959864
Kubitz JC, Forkl S, Annecke T, Kronas N, Goetz AE, Reuter DA: Systolic pressure variation and pulse pressure variation during modifications of arterial pressure. Intensive Care Med 2008, 34: 1520-1524. 10.1007/s00134-008-1114-8
Kim HK, Pinsky MR: Effect of tidal volume, sampling duration, and cardiac contractility on pulse pressure and stroke volume variation during positive-pressure ventilation. Crit Care Med 2008, 36: 2858-2862. 10.1097/CCM.0b013e3181865aea
Auler JO, Galas F, Hajjar L, Santos L, Carvalho T, Michard F: Online monitoring of pulse pressure variation to guide fluid therapy after cardiac surgery. Anesth Analg 2008, 106: 1201-1206. 10.1213/01.ane.0000287664.03547.c6
Cannesson M, Desebbe O, Rosamel P, Delannoy B, Robin J, Bastien O, Lehot J-J: Pleth variability index to monitor the respiratory variations in the pulse oximeter plethysmographic waveform amplitude and predict fluid responsiveness in the operating theatre. Br J Anaesth 2008, 101: 200-206. 10.1093/bja/aen133
Cannesson M, Slieker J, Desebbe O, Bauer C, Chiari P, Hénaine R, Lehot J-J: The ability of a novel algorithm for automatic estimation of the respiratory variations in arterial pulse pressure to monitor fluid responsiveness in the operating room. Anesth Analg 2008, 106: 1195-1200. 10.1213/01.ane.0000297291.01615.5c
Wyffels PA, Durnez PJ, Helderweirt J, Stockman WMA, De Kegel D: Ventilation-induced plethysmographic variations predict fluid responsiveness in ventilated postoperative cardiac surgery patients. Anesth Analg 2007, 105: 448-452. 10.1213/01.ane.0000267520.16003.17
Cannesson M, Attof Y, Rosamel P Desebbe O, Joseph P, Metton O, Bastien O, Lehot J-J: Respiratory variations in pulse oximetry plethysmographic waveform amplitude to predict fluid responsiveness in the operating room. Anesthesiology 2007, 106: 1105-1111. 10.1097/01.anes.0000267593.72744.20
Preisman S, Kogan S, Berkenstadt H, Perel A: Predicting fluid responsiveness in patients undergoing cardiac surgery: functional haemodynamic parameters including the respiratory systolic variation test and static preload indicators. Br J Anaesth 2005, 95: 746-755. 10.1093/bja/aei262
Hofer CK, Müller SM, Furrer L, Klaghofer R, Genoni M, Zollinger A: Stroke volume and pulse pressure variation for prediction of fluid responsiveness in patients undergoing off-pump coronary artery bypass grafting. Chest 2005, 128: 848-854. 10.1378/chest.128.2.848
Bendjelid K, Suter PM, Romand JA: The respiratory change in preejection period: a new method to predict fluid responsiveness. J Appl Physiol 2004, 96: 337-342. 10.1152/japplphysiol.00435.2003
Kramer A, Zygun D, Hawe H, Easton P, Ferland A: Pulse pressure variation predicts fluid responsiveness following coronary artery bypass surgery. Chest 2004, 126: 1563-1568. 10.1378/chest.126.5.1563
Schneider AJ, Teule GJ, Groeneveld AB, Nauta J, Heidendal GA, Thijs LG: Biventricular performance during volume loading in patients with early septic shock, with emphasis on the right ventricle: a combined hemodynamic and radionuclide study. Am Heart J 1988, 116: 103-112. 10.1016/0002-8703(88)90256-6
Natalini G, Rosano A, Taranto M, Faggian B, Vittorielli E: Arterial versus plethysmographic dynamic indices to test responsiveness for testing fluid administration in hypotensive patients: a clinical trial. Anesth Analg 2006, 103: 1478-1484. 10.1213/01.ane.0000246811.88524.75
De Backer D, Heenen S, Piagnerelli M, Koch M, Vincent JL: Pulse pressure variations to predict fluid responsiveness: influence of tidal volume. Intensive Care Med 2005, 31: 517-523. 10.1007/s00134-005-2586-4
Feissel M, Teboul JL, Merlani P, Badie J, Faller JP, Benjelid K: Plethysmographic dynamic indices predict fluid responsiveness in septic ventilated patients. Intensive Care Med 2007, 33: 993-999. 10.1007/s00134-007-0602-6
Vieillard-Baron A, Chergui K, Rabiller A, Peyrouset O, Page B, Beauchet A, Jardin F: Superior vena caval collapsibility as a gauge of volume status in ventilated septic patients. Intensive Care Med 2004, 30: 1734-1739.
Suffredini AF, Fromm RE, Parker MM, Brenner M, Kovacs JA, Wesley RA, Parrillo JE: The cardiovascular response of normal humans to the administration of endotoxin. N Engl J Med 1989, 321: 280-287. 10.1056/NEJM198908033210503
Kumar A, Bunnell E, Lynn M, Anel R, Habet K, Neumann A, Parrillo JE: Experimental human endotoxemia is associated with depression of load-independent contractility indices: prevention by the lipid a analogue E5531. Chest 2004, 126: 860-867. 10.1378/chest.126.3.860
Kumar A, Zanotti S, Bunnell G, Habet K, Añel R, Neumann A, Cheang M, Dinarello CA, Cutler D, Parrillo JE: Interleukin-10 blunts the human inflammatory response to lipopolysaccharide without affecting the cardiovascular response. Crit Care Med 2005, 33: 331-340. 10.1097/01.CCM.0000152229.69180.2
The Department of Intensive Care Medicine holds, or has in the past held, research contracts with Abbott Nutrition International, B. Braun Medical AG, CSEM SA, Edwards Lifesciences Services GmbH, Kenta Biotech Ltd, Maquet Critical Care AB, Omnicare Clinical Research AG, and Orion Corporation, and holds or has held research and development/consulting contracts with Edwards Lifesciences SA and Maquet Critical Care AB. The money is/was paid into a departmental fund; no author receives/received individual fees. The past contract with Edwards Lifesciences is unrelated to and did not influence the current study.
FD and DT carried out the animal experiments and analyzed a significant part of the data, and drafted the manuscript. SK participated in the experiments and analyzed the data. SMJ and JT designed and supervised the experiments, performed statistical analyses, and critically revised the manuscript.
Fritz Daudel, David Tüller contributed equally to this work.
